| Pump to Motor Foot Types |
3 |
| Motor Frame |
48 Frame Thru-Bolt, 56 Frame Thru-Bolt |
| Drain Plug Location |
3,4,6,9 o`clock |
| Suction Auxillary Port |
None |
| Suction Style |
Center |
| Suction Connection (Physical Dimension) |
3-11/16" od |
| Suction Connection Type |
Male Buttress Thread (mbt) |
| Suction Pipe Size |
2-1/2" |
| Discharge Auxilary Port |
None |
| Discharge Style |
Side |
| Discharge Connection (Physical Dimension) |
3-11/16" od |
| Discharge Connection Type |
Male Buttress Thread (mbt) |
| Discharge Pipe Size |
2-1/2" |
| Horsepower |
2.5hp |
| Manufacturer |
AquaFlo/Gecko |
| Pump Model |
Flo-Master XP3 |
| Manufacturer Impeller Number |
91698250 |
| Volute Fastening Type |
8 Screws |
| Volute/Sealplate Number |
92770735 |
